S3635A Test Blade OF UL498 Figure 109.2

Product No: GNGPL-S3635A

  • Specifications
  • Standards
  • Technology

  • Application:
    The S3635A Test Blade OF UL498 Figure 109.2 is a plug and socket test gauge utilized for testing the structure and size of plugs and sockets in accordance with UL 498:2012 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets and other similar areas.

    Feature:
    Gauge dimensions, tolerances, material, hardness, surface roughness conform to the standards requirements;
    Material hardness is more than 50HRC;Material thermal expansion coefficient is small,dimensions and tolerances is stable and reliable.

    Standard:
    UL 498 “Attachment Plugs and Receptacles” Figure 109.2

    S3635A Test Blade OF UL498 Figure 109.2

    S3635A Test Blade OF UL498 Figure 109.2
