VDE 0620-1 Lehre 16d – Lehre zur Prüfung der größten Abzugskraft des Steckers 2P AC 250 V 2,5 A

This VDE 0620-1 Lehre 16d – Lehre zur Prüfung der größten Abzugskraft des Steckers 2P AC 250 V 2,5 A is meticulously designed and manufactured in strict compliance with the relevant requirements of the VDE 0620-1:2010 standard. It is specifically developed to test the maximum withdrawal force of 2P AC 250 V 2.5 A plugs, ensuring that the connection stability and structural reliability of plugs and sockets meet industry safety and performance criteria, thus preventing unintended disconnection during daily use.

Specifications:
• Complies with DIN VDE 0620-1 “Plugs and socket-outlets for household and similar purposes – Part 1: General requirements on fixed socket-outlets” Lehre 16d
• Adheres to the VDE 0620-1:2010 standard
• Dedicated to testing the maximum withdrawal force of 2P AC 250 V 2.5 A plugs
• Engineered to verify the structural and dimensional compliance of plugs and sockets with standard requirements

Test Procedures:
• Prepare the 2P AC 250 V 2.5 A plug and its matching socket to be tested, ensuring they are clean, undamaged, and placed in a stable testing environment.
• Inspect the gauge to confirm it is intact, free from defects, and meets the specified manufacturing standards.
• Insert the plug fully into the socket in accordance with normal usage to achieve a secure connection.
• Attach the gauge to the plug correctly following standard operating protocols for withdrawal force testing.
• Apply a gradual and steady pulling force to the gauge until the plug is disconnected from the socket, recording the maximum force exerted during this process.
• Compare the recorded maximum withdrawal force with the requirements outlined in VDE 0620-1:2010 to determine if the plug and socket comply with the standard.

Applications:
• Maximum withdrawal force testing and quality inspection of 2P AC 250 V 2.5 A plugs in the electronics industry.
• Compliance verification of plug and socket connection reliability during production in the electrical appliance manufacturing sector.
• Routine quality control in plug and socket production enterprises to ensure consistent withdrawal force performance.
• Performance inspection of household and similar-purpose 2P AC 250 V 2.5 A electrical plugs and sockets.
• Research and development testing for new 2P plug designs to meet maximum withdrawal force standard requirements.
• Third-party certification and inspection services for 2P AC 250 V 2.5 A plug and socket products.
